BJT Transistor switching in Hindi. The dual diode model of the BJT transistor is explained in this video. Working Principle of the #BJT #transistor is briefly explained in our complete switching video course.

This is a demo video to the introduction of the complete laptop motherboard component #switching. The basic working of BJT is important for understanding the working of the laptop motherboard.

BJT is a three-terminal device Emitter, collector and base. The base acts as the controlling terminal for the flow of current between Collector to the emitter.

BJT is classified into two categories:-
1. NPN Transistor
2. PNP Transistor

NPN transistor consists of two back to back connected PN junction diode. While a PNP transistor consists of two face to face PN junction diode.

Base to emitter voltage is required to switch on or switch off the transistor.

When BJT is in Cut-off state then it is in Switch OFF condition while in the Saturation region the BJT behaves as an ON switch connecting Emitter to the collector.

Laptop repair training complete course. Online and offline laptop repairing training video course and advance chip level repairing training is provided by laptex.

Become a well-trained laptop technician with our lifetime support.

Laptex provides the complete component as well as chip level training with live practical on faulty motherboards to understand the application of the concept. As our slogan defines learn the logic concept.

For further query WhatsApp or call us

@ Mr. Nasir - +919871145066
@ Mr. Dildar - +919031240767

You can also visit our office @ 605A Sahyog building 6th floor Nehru place Delhi 110019.

Join our #course module and become an expert in laptop motherboard repairing. All are welcome to join our free Demo Class.
